WNS1.4 MW gas oil fired hot water boiler

WNS series hot water boiler adopts the most sophisticated three returns all wet back structure,thread smoke tube structure weld joint with high quality.

Reasonable boiler combustor design, suitable for different fuels such as diesel, natural gas, town gas and mazout, the fuels can burn completely and increasing the radiation heating furnace area,reducing the NOX emissions.

100% corrugated furnace and spirally corrugated tube, can absorb flame heat effectively, thermal efficiency can be more than 96%.
Inquire

  • WNS1.4

  • SWET

  • WNS1.4

  • Gas(oil)

  • Customer's Requirement

  • WNS1.4

  • Industrial Production

  • 0.7/1.0 mpa

  • 12 Months

  • 95/115℃

  • 95.52%

  • 1.4MW

  • WNS1.4 MW gas oil fired hot water boiler


   The series boiler is three-return fire tube hot water boiler.

   Atmosphere through three-return smoke tube, smoke chamber.

   It equipped with good performance burner and advanced techniques

   Simple operation, easy installation, high efficiency, less pollution and noise, etc

   It is widely used for factory, hotel, hospital, office building, etc

new steam boiler
Model Unit WNS1.4
Rated capacity MW 1.4
Working pressure Mpa 0.7(1.0)
Steam temperature ℃ 95(115)
Feed temperature ℃ 20
Testing efficiency ％ 95.52
Diesel consumption   Kg/h 138.34
 Gas consumption  Nm³/h 158.1
Outline dimension mm(L*W*H) 3270*1850*1930

boiler
